2022-2024 Cummins 6.7L AMDP EFILive Custom Tuning - No ECM Change Required

Name: 2022-2024 Cummins 6.7L AMDP EFILive Custom Tuning - No ECM Change Required
Brand: AMDP
SKU: 22-24-CUMM-AMDP-EFI
Price: 3425.0 CAD
Availability: InStock

SKU: 22-24-CUMM-AMDP-EFI

$3,425.00 CAD

All Digital Products (Custom Tuning, Tuning Revisions, Upgrades, and Credits) are Non-Refundable. Tune files are processed Monday-Friday and may take 24-48 hours to receive. Custom Tune files are not customized to your vehicles specifics. The files are pre-built by the vendors.

Product variants

Product details

Type Custom Tuning
Vendor AMDP
SKU 22-24-CUMM-AMDP-EFI

Tuning specifications

Tuning Device Required AutoCal V3
Tuning Platform EFILive

Have any questions about this product?

Ask a tuning expert at OCDiesel!

2022-2024 Cummins 6.7L AMDP EFILive Custom Tuning - No ECM Change Required

AMDP 2022-2024 6.7L Cummins EFILIVE Custom Tuning with NO ECM SWAP Required is now available.

Currently, this is a ZERO HP file with Emissions Removed.

Underhood EGR can be completely removed on this file.

Throttle valve needs to remain plugged in

This file requires switching the MAP sensor to Cummins PN:2897334

This product only supports 68RFE equipped trucks so NO High Output Aisin or Cab and Chassis trucks.

This product cannot add trans tuning, this is ECM tuning ONLY.

If the customer wishes to upgrade to ECM SWAP power-added tuning in the future there will be a separate item with that upgrade option as we will apply some credit towards that purchase.

We expedite our tune file delivery process by asking you for all the information we need to fully optimize your tune file before you order. Other tuning vendors may ask for no, or partial information, which they then inquire for after the order is placed leading to delays in getting you your tune files! We know your time is important, so once you fill out the form, your done! Because we do our custom tuning this way, our tuning division has industry leading turn-around times, averaging same day or next day deliveries on most files.

SOTF - Switch on the fly (If the Vehicle is equipped with a switch)
DSP5 - Duramax Switchable Programing (5 Tune Slots)
CSP5 - Cummins Switchable Programing (5 Tune Slots)
CSP4 - Cummins Switchable Programing (4 Tune Slots)
FT/FTP - Fuel Temp SOTF Switch
CAC - Charge Air Control SOTF Switch
LBF - Low Boost Fuel
RUMBLE - Rumble Idle Sound (VGT Turbos Only)
HISS - Hiss Idle Sound (VGT Turbos Only)
Em.on - Emissions On Tuning / Em.off - Emission Off Tuning
MODVGT - Modified VGT Turbo
NONVGT - Non VGT Turbo / Fixed Vein Turbo
4IN - 4 Inch Intake (Stock)
5IN - 5 Inch Instake
CP3 - CP3 Pump Conversions
KAM Reset - Load this tune first prior to installing any modified trans tuning files (FORD)
LSP - Low Shift Points
SSP - Standard Shift Points
RSP - Raised Shift Points
HSP - High Shift Points
ST – Single Fuel Tank
DT – Dual Fuel Tank
SRW – Single Rear Wheel
DRW – Dual Rear Wheel
MAN – Manual Transfer Case
ELEC – Electric Transfer Case

After ordering you will receive your vehicle tune file via email.
Before you begin, ensure your device firmware and EFI software are up to date
Install Cummins Security Bypass cable
Place key in RUN position (DO NOT START) and remove fuses numbered: 49,51,33,54,57,66,82,88 to prevent any BUS flashing issues. Yes, you interior lights and dash will shut off when you pull the fuses.
Flash tune file with your EFILive device.
When complete, reinstall fuses and you're good to go!

Note: If flashing ECM on bench, or using BenchForce harness to connect directly to the ECM, it is not required to do anything with the vehicle fuses. Just flash directly into the ECM like normal.
